Water connection set

Back grill

XP26DCSI-PLUS-POS-4

Side grill

XP26DCSI-PLUS-POS-5

Sensor casing pipe

XP26DCSI-PLUS-POS-7

Evaporator distribution piping

XP26DCSI-PLUS-POS-8

Right side panel

XP26DCSI-PLUS-POS-9

PFC inductor

XP26DCSI-PLUS-POS-10

Fan motor plate

XP26DCSI-PLUS-POS-11

Capacitor clamp

XP26DCSI-PLUS-POS-12

Fan motor

XP26DCSI-PLUS-POS-13

Pillar

XP26DCSI-PLUS-POS-14

Evaporator heating belt clip

XP26DCSI-PLUS-POS-15

Evaporator heating belt 230V 65W 2000mm

7020274

Fan motor bracket

XP26DCSI-PLUS-POS-17

Fan motor YDK-50-8CXX 50W

7021813

Fan bracket

XP26DCSI-PLUS-POS-19

Fan blade 470mm x 125mm, 12mm hole clockwise

7010540

Left side panel

XP26DCSI-PLUS-POS-21

Fan bracket

XP26DCSI-PLUS-POS-22

Front panel

XP26DCSI-PLUS-POS-23

Cable clip

XP26DCSI-PLUS-POS-24

LED display inverter SHCLEDPMM101

7020256

Fan motor bracket

XP26DCSI-PLUS-POS-28

Drain valve

XP26DCSI-PLUS-POS-31

Fluid reservoir

XP26DCSI-PLUS-POS-32

Compressor heating belt 230V 35W 430mm

7020270

Inverter compressor 26

XP26DCSI-PLUS-POS-35

LED display inverter WIFI02MM011

7023600

Motor bracket

XP26DCSI-PLUS-POS-29

Base tray

XP26DCSI-PLUS-POS-30

Compressor damping feet

XP26DCSI-PLUS-POS-34

Power cord base

XP26DCSI-PLUS-POS-37

Terminal bracket

XP26DCSI-PLUS-POS-38

Terminal panel bracket

XP26DCSI-PLUS-POS-39

Pillar

XP26DCSI-PLUS-POS-40

Wiring cover

XP26DCSI-PLUS-POS-41

Water switch 3-seat terminal

XP26DCSI-PLUS-POS-42

Right panel

XP26DCSI-PLUS-POS-43

Terminal wiring block

XP26DCSI-PLUS-POS-44

Assembly Collective pipe

XP26DCSI-PLUS-POS-45

Exchanger to filter

XP26DCSI-PLUS-POS-46

Filter

XP26DCSI-PLUS-POS-47

Electronic expansion valve

XP26DCSI-PLUS-POS-48

EEV to distribution piping

XP26DCSI-PLUS-POS-49

Suction pipe TH1

XP26DCSI-PLUS-POS-50

4-way valve to Exchanger

XP26DCSI-PLUS-POS-51

4-way valve

XP26DCSI-PLUS-POS-54

Exhaust pipe

XP26DCSI-PLUS-POS-55

Low pressure switch 0.2 - 0.35Mpa

7024792

Suction pipe

XP26DCSI-PLUS-POS-58

4-way valve to collective piping

XP26DCSI-PLUS-POS-59

Titanium heat exchanger

XP26DCSI-PLUS-POS-60

Blue rubber ring

XP26DCSI-PLUS-POS-62

White rubber ring

XP26DCSI-PLUS-POS-63

Water flow switch XH-2 plug (6x4mm)

7020258

Water in temperature sensor TH1 plug (6x4)

7020264

Water in temperature sensor clip

XP26DCSI-PLUS-POS-68

Blue rubber ring

XP26DCSI-PLUS-POS-70

Titanium heat exchanger

7021823

Water out temperature sensor TH2 plug (6x4)

7020265

Manometer housing thread 10bar black

011241

Electric box cover

XP26DCSI-PLUS-POS-74

Main board inverter Z63X

7020767

Wire casing

XP26DCSI-PLUS-POS-77

Air conditioner Relay

XP26DCSI-PLUS-POS-78

Sharing terminal

XP26DCSI-PLUS-POS-79

AC reactor inductance

XP26DCSI-PLUS-POS-80

Main board inverter Z6

7020763

Transformer

XP26DCSI-PLUS-POS-82

Module board

XP26DCSI-PLUS-POS-83

Electric box

XP26DCSI-PLUS-POS-84
