Verwarmingsspiraal spalk

Front and rear middle beams

7037571-POS-7

Installation plate of side base

7037571-POS-8

Titanium tube heat exchanger

7038178

Electric expansion valve

7037571-POS-10

Filter

7037571-POS-11

Needle valve

7037571-POS-12

Needle valve

7037571-POS-13

Compressor

7037571-POS-14

Triangular plate

7037571-POS-15

Water proof middle plate

7037571-POS-16

Column assembly

7037571-POS-17

Compressor cover side plate 1

7037571-POS-18

Compressor cover side plate 2

7037571-POS-19

Compressor cover plate 1

7037571-POS-20

Compressor cover plate 2

7037571-POS-21

Lower panel

7037571-POS-22

Fan box assembly

7037571-POS-23

Fin sealing plate 2

7037571-POS-24

Triangle of side base

7037571-POS-25

Lower panel

7037571-POS-26

Fin sealing plate

7037571-POS-27

Detachable water tray 4

7037571-POS-28

Detachable water tray 1

7037571-POS-29

Detachable water tray 2

7037571-POS-30

Detachable water tray 3

7037571-POS-31

Water tray assembly

7037571-POS-32

Fin sealing plate top 2

7037571-POS-33

Width of air guide ring

7037571-POS-34

Bracket dc-motor

7037571-POS-35

Axial fan blade

7038180

Fan guard

7037571-POS-38

Three-way valve

7037571-POS-39

Four way valve Y-type

7037571-POS-40

Top panel assembly

7037571-POS-42

Fuse box

7037571-POS-44

Terminal block

7037571-POS-45

AC contactor

7037571-POS-46

Terminal block

7037571-POS-47

AC filter

7038183

Filter board

7037571-POS-49

Front panel of electrical box

7037571-POS-50

Electrical box lining plate

7037571-POS-51

Electrical box installation frame

7037571-POS-52

Electrical box assembly

7037571-POS-53

Module with temperature controller

7037571-POS-54

3-bit block

7037571-POS-55

Relay

7037571-POS-56

Inverter board

7037571-POS-57

Flagship copper tube lower splint

7037571-POS-58

Flagship copper tube upper splint

7037571-POS-59

Clapboard of Electric heating

7037571-POS-60

Reactor

7037571-POS-61

Explosion proof box base assembly

7037571-POS-62

AC contactor

7037571-POS-63

Explosion proof box top cover

7037571-POS-64

AC fan drive board

7038184

Display

7038185
