Verdamper

Evaporator piping pipe

XP21DCSI-PLUS-POS-6

Clip

XP21DCSI-PLUS-POS-7

Reactor

XP21DCSI-PLUS-POS-9

Base

XP21DCSI-PLUS-POS-10

Top Frame

XP21DCSI-PLUS-POS-11

Evaporator heating belt clip

XP21DCSI-PLUS-POS-12

Fan motor bracket

XP21DCSI-PLUS-POS-14

Left side panel

XP21DCSI-PLUS-POS-17

Front panel

XP21DCSI-PLUS-POS-18

Front grill

XP21DCSI-PLUS-POS-19

Wiring box

XP21DCSI-PLUS-POS-20

Wire connection

XP21DCSI-PLUS-POS-24

Terminal

XP21DCSI-PLUS-POS-25

Compressor

XP21DCSI-PLUS-POS-26

Compressor hair

XP21DCSI-PLUS-POS-27

Compressor heating belt 230V 35W 320mm

7020269

Compressor anti-piping feet

XP21DCSI-PLUS-POS-29

Terminal panel

XP21DCSI-PLUS-POS-30

Pressure gauge

XP21DCSI-PLUS-POS-32

Bottom panel

XP21DCSI-PLUS-POS-33

Right panel

XP21DCSI-PLUS-POS-34

Isolation panel

XP21DCSI-PLUS-POS-35

Assembly distribution piping

XP21DCSI-PLUS-POS-36

Piping

XP21DCSI-PLUS-POS-37

Profile Rubber fixing block

XP21DCSI-PLUS-POS-38

Back panel

XP21DCSI-PLUS-POS-39

Expansion gas filter

XP21DCSI-PLUS-POS-40

Filter

XP21DCSI-PLUS-POS-41

Suction valve

XP21DCSI-PLUS-POS-42

Reservoir to EEV

XP21DCSI-PLUS-POS-43

High pressure meter

XP21DCSI-PLUS-POS-44

Back gas piping

XP21DCSI-PLUS-POS-47

4-way valve to collective piping

XP21DCSI-PLUS-POS-49

Suction pipe

XP21DCSI-PLUS-POS-50

4 way valve

XP21DCSI-PLUS-POS-51

Return distribution piping

XP21DCSI-PLUS-POS-52

Electronic expansion valve

XP21DCSI-PLUS-POS-53

Water inlet temperature sensor TH5

XP21DCSI-PLUS-POS-56

O-ring Sealing ring

XP21DCSI-PLUS-POS-58

Blue rubber ring

XP21DCSI-PLUS-POS-59

Flow switch connector 1/2” F/F PP

XP21DCSI-PLUS-POS-63

Red rubber ring

XP21DCSI-PLUS-POS-65

Sealing ring

XP21DCSI-PLUS-POS-67

Magnet ring

XP21DCSI-PLUS-POS-68

Rubber ring

XP21DCSI-PLUS-POS-69

Wire casing

7020762

Main board inverter 21 Electric box cover

XP21DCSI-PLUS-POS-71
